Type:CRSSHV(High voltage reed relay)	Cont form:1 Form A(1M)
Rating load:50W	R on (ohm):150m
Contact Form:1A	Load(V):DC.10KV
Load(I):2A	T on:4mS
Cout typ:2.0pF	Breakdown volt:DC.14KV
Data Sheet Download

Features:
· High Breakdown Voltage Reed relay. ·High Current and Power Reed Relay. ·Low and Stable Contact Resistance. · Low Stray Capacitance, · Magnetic Shield Options.
